Honeywell Orbit 7120 Omnidirectional Laser Scanner Kit (Black)
BZ$600.00
GST included, shipping calculated at checkout
The Orbit 7120 Omnidirectional Laser Scanner Kit from Honeywell includes a mounting plate and a 9.2' USB cable. The Orbit is a hands-free omnidirectional scanner with a patented 20-line scan pattern, an easy-to-find sweet spot, and a scan speed of 1,067 scans per second. Electrical Input Voltage 5 VDC ± 0.25 V Operating Power...
Return Policy
The Orbit 7120 Omnidirectional Laser Scanner Kit from Honeywell includes a mounting plate and a 9.2' USB cable. The Orbit is a hands-free omnidirectional scanner with a patented 20-line scan pattern, an easy-to-find sweet spot, and a scan speed of 1,067 scans per second.
Electrical
| Input Voltage | 5 VDC ± 0.25 V |
| Operating Power | 900 mW (180 mA @ 5 V) |
| Standby Power | 850 mW (170 mA @ 5 V) |
| System Interface | USB, RS232, Keyboard wedge, IBM 468xx (RS485), light pen wand emulation |
Scan Quality
| Scan Pattern | 5 fields of 4 parallel lines (omnidirectional) |
| Scan Speed | 1,067 scans per second |
| Print Contrast | 35% minimum reflectance difference |
| Pitch | 60° |
| Skew | 60° |
| Decoding Formats | Reads standard 1D and GS1 DataBar symbologies |
| System Requirements | Works on all Mac and PC operating systems |
| Depth of Field | Narrow Width / Depth of Field 5.2 mil / 0.0 - 2.0" (0.0 - 50.0 mm) 7.5 mil / 0.0 - 5.9" (0.0 - 150.0 mm) 10.0 mil / 0.0 - 6.9" (0.0 - 175.0 mm) 13.0 mil / 0.0 - 8.5" (0.0 - 215.0 mm) 26.0 mil / 0.0 - 9.8" (0.0 - 250.0 mm) |
Environmental
| Storage Temperature | -40° to 140°F (-40° to 60°C) |
| Operating Temperature | 32° to 104°F (0° to 40°C) |
| Humidity | 5% to 95% relative humidity, non-condensing |
| Durability | Designed to withstand 4.0' (1.2 m) drops |
| Sealing | Sealed to resist airborne particulate contaminates |
| Lighting Conditions | 4842 lux |
Physical
| Dimensions | 4.1 x 4.0 x 5.9" (105.0 x 102.0 x 150.0 mm) |
| Weight | 14.1 oz (400.0 g) |
Packaging Info
| Package Weight | 1.7 lb |
| Box Dimensions (LxWxH) | 9.8 x 7.7 x 3.4" |
